OVERVIEW
Keep an Eye on Your Environment from Miles Away
The HOBOnet Wireless Temperature Sensor provides a cost-effective and scalable solution for web-enabled monitoring of air temperature. HOBOnet wireless sensors communicate data directly to a HOBO RX Station or pass data through other wireless sensors back to the central station. They are preconfigured and ready to deploy, and data is accessed through the LI-COR Cloud IoT platform (formerly HOBOlink).
Features
Sensor Features
- Measurement range of -40° to 100°C (-40° to 212°F)
- High accuracy: ± 0.2°C ( ± 0.36°F)
- Stainless-steel sensor tip
Wireless Features- 900 MHz wireless mesh self-healing technology
- 450 to 600 meter (1,500 to 2,000 feet) wireless range and up to five hops
- Up to 50 wireless sensors or 336 data channels per HOBO RX station
- Simple button-push to join the HOBOnet wireless network
- Onboard memory to ensure no data loss
- Powered by rechargeable AA batteries and built-in solar panel
Important Information
Includes lithium batteries. A complete system requires a HOBO RX Station, a HOBOnet Wireless Manager, and a HOBOnet Wireless Sensor. HOBOnet Wireless Repeaters can be added to extend the range of both system options.
-
SPECIFICATIONS
Sensor
Measurement Range -40° to 100°C (-40° to 212°F) Accuracy ±0.25°C from -40° to 0°C (±0.45°F from -40° to 32°F)
±0.20°C from 0° to 70°C (±0.36°F from 32° to 158°F)
±0.25°C from 70° to 100°C (±0.45°F from 158° to 212°F)Resolution 0.02°C (0.036°F) Drift <0.01°C (0.018°F) per year Response Time (typical, to 90% of change) 2 minutes, 30 seconds in air moving 1 m/sec Wireless Mote
Operating Temperature Range -40° to 70°C (-40° to 158°F) Radio Power 12.6 mW (+11 dBm) non-adjustable Transmission Range Reliable connection to 457.2 m (1,500 ft) line of sight at 1.8 m (6 ft) high
Reliable connection to 609.6 m (2,000 ft) line of sight at 3 m (10 ft) highWireless Data Standard IEEE 802.15.4 Radio Operating Frequencies RXW-TMB-x-900: 904–924 MHz
RXW-TMB-x-868: 866.5 MHz
RXW-TMB-x-921: 921 MHz
RXW-TMB-x-922: 916–924 MHzModulation Employed OQPSK (Offset Quadrature Phase Shift Keying) Data Rate Up to 250 kbps, non-adjustable Duty Cycle <1% Maximum Number of Motes Up to 50 wireless sensors or 336 data channels per one HOBO RX station Logging Rate 1 minute to 18 hours Number of Data Channels 2 Battery Type Two AA 1.5 V lithium batteries Battery Life 1 year, typical use Memory 16 MB Dimensions Sensor: 5.1 x 33 mm (0.2 x 1.3 inches)
Cable length: 0.3 m (1 ft), RXW-TMB-1-xxx; 1.8 m (6 ft), RXW-TMB-6-xxx
Mote: 16.2 x 8.59 x 4.14 cm (6.38 x 3.38 x 1.63 inches)Weight Sensor and cable: 7.6 g (0.27 oz), RXW-TMB-1-xxx; 35.2 g (1.24 oz), RXW-TMB-6-xxx
Mote: 223 g (7.87 oz)Materials Sensor: Stainless steel waterproof tip
Mote: PCPBT, silicone rubber sealEnvironmental Rating Sensor and cable: Immersion in water up to 50°C (122°F) for 1 year
Mote: IP67, NEMA 6Compliance Marks See User Manual
HOBOnet Wireless Temperature Sensor (Battery Powered)
$459.80 – $485.10 NZD ex GST
The HOBOnet Wireless Temperature Sensor provides a cost-effective and scalable solution for web-enabled monitoring of air temperature.
