OVERVIEW
Alerts when motion is detected
Discover motion with ease using the Power-over-Ethernet (PoE) Motion Detection (PIR) Sensor, which tracks movement through the power of infrared technology. Thanks to iMonnit’s online system, all gathered data is available for review and export in just a few clicks as either a data sheet or graph. Plus, set up convenient notifications to alert you whenever motion is detected. Perfect for boosting security and tracking building traffic for sanitation purposes, these passive infrared (PIR) sensors are a game-changer.
The Power-over-Ethernet (PoE) Sensor products measure various conditions (environmental, power, access). All devices come with flexible settings – including notifications, alerts, reports, and maps – can be customized in the iMonnit online sensor management interface.
Monnit’s Power over Ethernet sensors integrate with a building’s PoE network; it can also be used with a standard Ethernet infrastructure and powered via an optional AC adapter.
Features
- Power-over-Ethernet ready (injector hardware required)
- Embedded LEDs for transmission & online condition indicators
- 50,000 sensor message memory (non-volatile)
- Modbus TCP & SNTP v1 interface capabilities
- No PC required (managed through apps and smart devices)
- Remote update capable w/automatic updates
Applications
- Area Access Monitoring
- Restricted area monitoring
- Room occupancy monitoring
- Vacant Property monitoring
-
SOFTWARE
Manage Your Monnit Sensors with iMonnit Cloud-based Software
Monnit’s Sensor Monitoring Software, iMonnit, stands as a cutting-edge cloud-based platform and central hub tailored for the seamless management of Monnit sensors. With a focus on data security, all information is safeguarded on dedicated servers running Microsoft SQL Server. This intuitive online user interface serves as a command centre for arranging, monitoring, and modifying device settings to suit individual requirements.
OneTemp provides complimentary activation and setup services for new iMonnit accounts, while a free mobile app empowers users to maintain control at all times. Whether opting for the basic version or upgrading to iMonnit Premiere, users can unlock the full spectrum of features that enrich the Monnit experience.
Click here to explore the software options >>
-
SPECIFICATIONS
Part Number MNS-P-C1-MS-IR Communication Hardware 10 / 100 Ethernet Controller PoE Requirements Class 1 Device (500mW) IEEE Standard Compliance 802.3AF-2003 / 802.3AT-2009 Class 1 Operation Full- and Half-Duplex Cross-Over Correction Automatic MDI / MDI-X Protocols Supported DHCP, DNS, NTP, UDP, TCP, SNMP, Modbus TCP Input Power Supplementary Power Requirement Cable Connector RJ45 Supplementary Power Connector 2.1 x 5.5 mm barrel jack, center positive Device Memory Up to 50,000 sensor messages; varies based on sensor type. (Sensor messages will be stored in the event of Internet outage and transferred when connection is restored.) Forced Communication / Reset Hardware Button Operating Temperature -20 to +60°C (-4 to 140°F) Storage Temperature -40 to +85°C (-40 to 185°F) Sensor Specifications
Software Adjustable Sensor Detection Range 15 ft (4.5 m)/12 ft (3.7 m)/9 ft (2.7 m) Sensor Warm-up Time 30 Seconds Weight 4.34 oz. (123 g)
Monnit PoE•X Infrared Motion and Occupancy Sensor
$513.70 NZD ex GST
Monitor movement by people or animals in virtually any area or facility. The passive infrared (PIR) ALTA Motion Detection Sensors help you increase security, coordinate building occupancy services and space booking, and safeguard critical assets and equipment by recording heat signals.
